Solid block

Comparison of the solid stone and liquid water blocks

Solid blocks consist of any type of block that has a collision box that players, mobs, or other entities cannot simply move through, and have to move on top of it or around.

Properties

Mobs require a solid top surface to spawn. Some mobs are able to spawn inside of the space occupied by another block, but only if their hitbox does not intersect the collision of any solid block.

Players, mobs, and other entities can walk on top of solid blocks. Particles that are affected by gravity (e.g. slime particles or water drip particles) also collide with solid blocks.

Full blocks

If a solid block's collision box is a full cube that is solid on all sides, it is known as a full block. For example, stone, planks, and glass are full blocks, but stairs, fences, and chests are not. For most blocks, it's easy to tell whether they're full blocks or not, but some are not so obvious:

Cauldrons and composters are not full blocks because their top face is not fully solid.
Scaffolding is not a full block because although its interaction box occupies the full block, its collision box does not.
Dirt path and farmland are not full blocks because they are slightly shorter than a full block.
Mud and soul sand are not full blocks despite visually appearing to be because their collision boxes are shorter than their models, so entities standing on top "sink into" the blocks.

Whether or not a block is a full block can influence some game mechanics. For example, endermen will only place blocks on top of full blocks and hoppers will not try to collect item entities if their top face is covered by a full block.

List of blocks

List of solid blocks

The following blocks are all solid blocks. They are categorized by their material.

Material	Blocks
Dirt
Wood
Stone
Metal
Decoration
Plants
Wool
Sand
Glass
Ice
Amethyst
Sculk
Other

List of non-solid blocks

The following is a list of blocks that are not solid. They are categorized by their material.

Material	Blocks
Air	Air
Water
Lava
Bubble column
Plants
Replaceable plants
Replacable water plant
Water plant
Fire
Decoration
Snow
Portal
Structural air
Coral
Web
Wood	^{[note 1]}^{[note 2]}
Other

↑ Hanging signs' mounting bracket is always solid.
↑ The top part is solid when standing on it, otherwise, players can phase through it by the sides.

Height

This section needs to be updated.

Please update this section to reflect recent updates or newly available information.
Reason: List the ones in Bedrock Edition (due to a bug, they are different)

Most solid blocks are 1 block in height, but certain blocks have non-standard block heights.

A player can automatically step up from a lower to a higher height, if the difference is at most 0.6 (³⁄₅) of a block. From ground level, this is anything the height of a chain or less.

A player can fit through spaces as small as 1.8125 (²⁹⁄₁₆) blocks high, since players are 1.8 blocks tall. This allows players to fit through a 2-block gap with a floor as high as a trapdoor.

When sneaking, a player can fit through spaces as small as 1.5 blocks, since sneaking players are 1.5 blocks tall, respectively. Players can fit through a 2-block space with a floor as high as a slab.

When gliding with elytra, a player can fit through spaces as small as 0.625 (⁵⁄₈) blocks high, since gliding players are 0.6 blocks tall. This allows players to fit through a 1-block gap with a floor as high as 4 layers of snow, a flower pot, or a daylight detector.

Note that doors, although appearing to be one 2-meter-high block, are actually composed of two (top and bottom) 1-meter-high blocks.

Here is a list of blocks with non-standard heights, from tallest to shortest in height:

Height			Block types
Decimal	Fractional	Pixelspace	Block types
1.5	1 ¹⁄₂	24	Open shulker boxes, fences, closed fence gate, walls.^{[note 1]}
1.25	1 ¹⁄₄	20	(Sticky) piston head facing down when `short=false`.^{[note 1]}
0.9375	¹⁵⁄₁₆	15	Dirt path, farmland, [[honey block\|honey block‌]], [[cactus\|cactus‌]], top part of a single_wall/double_wall bell, non-drip big dripleaf.^{[note 1]}
0.875	⁷⁄₈	14	Soul sand^{[note 2]}, mud, 8 layers of snow, top part of lectern, chest, ender chest, trapped chest, top part of brewing stand, stone part of wall grindstone, candle part of candle cake.^{[note 1]}
0.8125	¹³⁄₁₆	13	End portal frame without eye, frame part of end portal frame with eye, chorus plant when `up=false`, leg part of floor grindstone, center part of a single_wall/double_wall/ceiling bell, partial big dripleaf; medium amethyst bud, large amethyst bud, and amethyst cluster when placed on the wall.^{[note 1]}
0.75	³⁄₄	12	Enchanting table, 7 layers of snow, cocoa plant on any age, head\|wall heads, stone part of ceiling grindstone, extended (sticky) piston when facing up, small amethyst bud when placed on the wall.^{[note 1]}
0.6875	¹¹⁄₁₆	11	Conduit^[Java Edition only], Inside of hopper, top leg part of wall grindstone, up tip pointed dripstone.^{[note 1]}
0.625	⁵⁄₈	10	6 layers of snow, sideways end rod and lightning rod, bottom leg part of wall grindstone, top part of hanging lantern and soul lantern, the arm part of (sticky) piston head when facing east/north/south/west, dried ghast.^{[note 1]}
0.59375	¹⁹⁄₃₂	9¹⁄₂	Sideways chain.^{[note 1]}
0.5625	⁹⁄₁₆	9	Beds, stonecutter, top part of non-hanging lantern and soul lantern, bottom leg part of ceiling grindstone.^{[note 1]}
0.5	¹⁄₂	8	Bottom slabs, bottom part of bottom stairs, 5 layers of snow, heads on ground, 0-6 bite(s) of cake, cake part of candle cake, bottom part of hanging lantern and soul lantern, the mouth part of a/an east/north/south/west hopper, sculk sensor, calibrated sculk sensor, sculk shrieker.^{[note 1]}
0.4375	⁷⁄₁₆	7	Campfire, soul campfire, 1-4 turtle egg, 4 sea pickle, bottom part of non-hanging lantern and soul lantern, amethyst cluster when placed on the floor.^{[note 1]}
0.375	³⁄₈	6	Daylight detector, 4 layers of snow, flower pot and their potted variants, 1-3 sea pickle, bottom part of a single_wall/double_wall/ceiling bell, 1-4 candle(s).^{[note 1]}
0.3125	⁵⁄₁₆	5	Inner part of an anvil's base, large amethyst bud when placed on the floor, pitcher plant that have the age > 0.^{[note 1]}
0.25	¹⁄₄	4	3 layers of snow, base of (sticky) piston head when facing down, inside of cauldron, outer part of an anvil's base, medium amethyst bud when placed on the floor.^{[note 1]}
0.1875	³⁄₁₆	3	Bottom trapdoors, small amethyst bud when placed on the floor, age-0 pitcher plant.^{[note 1]}
0.125	¹⁄₈	2	Redstone repeater, redstone comparator, bottom of floating scaffolding, base of lectern, 2 layers of snow, base of brewing stand, inside of composter.^{[note 1]}
0.09375	³⁄₃₂	1¹⁄₂	Lily pad.^{[note 1]}
0.0625	¹⁄₁₆	1	Carpets (including moss carpet).^{[note 1]}

Width

Many blocks are less than 1 meter wide on one or more sides.

The table below shows the widths of various blocks. If a block has several hit boxes of different sizes (for example: brewing stands), then each hitbox is listed separately. Blocks with sides of different widths are listed with cardinal directions (north, south, east, west) for each side, assuming that the block was placed from above, with the player facing north.


Width			Block types
Decimal	Fractional	Pixelspace	Block types
1	1	16	Full block, the front of grindstone, anvil, and non-hanging bell.
0.9375	¹⁵⁄₁₆	15	Chest, trapped chest, ender chest, decorated pot, cactus, dragon egg, cake, cake part of candle cake, the behind of cocoa, 2-4 turtle egg, honey block, base of brewing stand.
0.875	⁷⁄₈	14	The outside of anvil, 3-4 sea pickle, the side of floor grindstone, the inside of azalea.
0.8125	¹³⁄₁₆	13	Cake 1, chorus plant, the inside of anvil, 2 sea pickle, 1 turtle egg, the leg part of wall grindstone, the wood part of wall bell, medium amethyst bud.
0.75	³⁄₄	12	The side of wall heads, the base extended (sticky) piston, walls when `up=true`, the side of age 2 cocoa, the center part of hopper and lectern, grindstone (wall) main part, bell (floor), bell (wall) main part, bell (ceiling) main part, small amethyst bud (facing east, west), the inside of azalea.
0.6875	¹¹⁄₁₆	11	Cake 2, end portal frame eye part, walls (up=false), cocoa 1 (facing east, west), conduit, grindstone (floor, facing north, south) leg part, lantern, bell (wall) middle part, candle 2 (west, east side), candle 3 (west, south side), candle 4 (west, east, north side).
0.625	⁵⁄₈	10	Fences, end rod, fence gates, piston arm, hopper tip, sea pickle 1, lantern top, candle 2 (north side), candle 3 (north, east), candle 4 (south side), azalea stem, azalea inside, lightning rod.
0.59375	¹⁹⁄₃₂	9.5	Chain.
0.5625	⁹⁄₁₆	9	Cake 3, iron bars, glass pane, the center of brewing stand, cocoa 2 front, grindstone on side thick leg, wall bell top part, candle 1, candle 2 south.
0.5	¹⁄₂	8	wall heads, stairs, the inside of azalea.
0.4375	⁷⁄₁₆	7	Cake 4, cocoa 1 front, amethyst cluster.
0.375	³⁄₈	6	The inside of azalea.
0.3125	⁵⁄₁₆	5	Cake 5, cocoa 0 front, large amethyst bud.
0.25	¹⁄₄	4	Piston arm front, cauldron leg outside, medium amethyst bud.
0.1875	³⁄₁₆	3	Trapdoors side, cake 6, doors, ladder, bed legs, small amethyst bud.
0.125	¹⁄₈	2	Hopper inside, cauldron inside, cauldron inside leg, the inside of azalea.
0.0625	¹⁄₁₆	1

↑ ^a ^b ^c ^d ^e ^f ^g ^h ⁱ ^j ^k ^l ^m ⁿ ^o ^p ^q ^r ^s These blocks are also thinner, i.e. their length and width are less than that of a full block.
↑ Soul sand has inner collision boxes every eighth of a block, so there is a collision box at 1/8, 2/8, 3/8, 4/8, 5/8, and 6/8.
