What is optocoupler and how it is used?

Question

Im curious about optocoupler.

What is optocoupler,why and how it is used in electronic circuits ?

What research have you already done? What do you already know abou this topic, and what specific question about it can we help you with? — The Photon, Oct 26 '18 at 22:27
I read about it a little on google,but I do not get it really. I want to know how it is used in circuits and why. — Бојан Долић, Oct 26 '18 at 22:31
Possible duplicate of How do I select the accompanying components for an optocoupler? — Dmitry Grigoryev, Oct 29 '18 at 09:16

score 1 · Accepted Answer · answered Oct 27 '18 at 01:28

1

an optocoupler is a device used when you want to electrically isolate a circuit from another circuit that you want to send an electric signal

when you turn on the led it sends photons to the phototransistor, these phototransistor which is like a normal transistor but its "base current" is the light emitted by the led, in this way you can use it as an isolated switch between two circuits

using an optocoupler to control a 12v load with a 3v3 signal

answered Oct 27 '18 at 01:28

Lucas Alexandre

676
6
16

Is there a reason they usualy put the R1 at pin 2 instead of pin 1? – floppy380 Oct 27 '18 at 18:15
i dont see a particular reason, in this circuit instead of the internal LED lighting up with a 3.3V signal it will light up with a 0V signal. a more experienced user could point out a better reason for this but i think is an inheritance from the old bjt transistor low side switching circuits. – Lucas Alexandre Oct 28 '18 at 02:34

score 0 · Answer 2 · answered Oct 26 '18 at 22:39

What is an optocoupler?

It's a device that couples an electronic signal from an input to an output optically. In practice, that means it has an LED for an input, a photodiode or phototransistor for a detector, and possibly some logic or other devices conditioning the output.

How is it used in electronic circuits?

It's used when you need to communicate between two circuits while maintaining electrical isolation, either as a safety isolation or as a designer convenience.
