For a project I'm working on we are orienting on the available mobile data connections. Because the current cellular connections are in a transition from G to LTE, I'm not sure whats the right desicion. From what I read about the 2G and 3G networks I have the feeling that theyre not going to be supported another 10 - 15 years. The 3G network is sure to shut down anytime soon (2021 in USA). The 2G network is a bit more complicated. Some providers say they will keep the 2G network alive because of many M2M applications use the 2G network. Some say the network will shutdown soon like 3G.

The reason I want to explore the possibilities with 2G is the (module) price and the worldwide coverage. These are the criteria for my project:

  • M2M
  • Embedded module with serial interface
  • As cheap as possible (module and price/mb)
  • Speed is not so much of a concern. 2G speed (56kbps) is sufficient
  • Worldwide support
  • Supported for another 15 years (the lifetime of our assets)

Next to the 'old' 2G 3G and 4G networks the LTE cat-m is coming up. LTE cat-me seems to be the right choice for M2M solutions in the future. This might be interesting for us, but the problem is that the network is upcoming and not avaliable globally. I think that it can take a few years before its globally supported. Besides that, the price/mb is going to be higher than the 2G/3G/4G prices as we know them.

I hope someone can clear things up.

Jan Roorda
  • 161
  • 3

2 Answers2

6

LoRaWAN

You might consider LoRaWAN.

In Belgium & The Netherlands LoRaWAN coverage is pretty good in populated areas; both free and for a fee. Traditional cellular providers in a number of Western European countries are also catching up with LoRaWAN: KPN (Netherlands), Proximus (Belgium), Swisscom, Orange (France)…

Figure: Wireless Things coverage map in Belgium & The Netherlands Wireless Things coverage map in Belgium & The Netherlands

Hopefully, the same will happen in the US — instead of the usual «not-invented-here» syndrome.

On the other hand, if you can afford a module like Pycom's FiPy one does not even need to chose a network…

Crystal ball articles

Finally, here is a still relevant December 2015 article trying to predict the future of LoRa vs LTE-M vs Sigfox. Even more US alternatives are mentioned in this article.

There is also a more recent January 2017 article for NB-IOT vs. LoRa vs. Sigfox.

PS: In my surroundings, quite a bit of people (myself included) still hold dear to their sturdy, spyware-free 2G phones with a battery standby time of two weeks. Hopefully, for some more years to come…

Community
  • 1
Serge Stroobandt
  • 211
  • 2
  • 7
5

Sigfox

Sigfox pretends to become a global LPWAN operator using proprietary uplink-only narrow-band LPWAN technology over a subscription-based proprietary network. All data will have to pass Sigfox servers.

They are VC funded, so the investors will want to make a return or eventually bail out. That, more than the technology, may determine their longevity and what comes afterwards. [Source]

Coverage

Sigfox coverage is published on a live map.

Sigfox legal limitations

Sigfox signals have a much lower bandwidth than LoRaWAN chirp spread spectrum signals that are typically 125kHz wide. Hence, Sigfox signals will require considerably more time to transmit the same amount of information. This limits the applicability in Europe where the transmission duty cycle is restricted to 1%.

As the current version of Sigfox uses public radio frequencies (aka ISM bands), we have to comply with the sharing rules in place in the different regions of the world to keep these bands available for everybody.

For instance, in Europe, the ETSI regulation allows devices on these frequencies to send messages for 1% of the time per hour. Devices can only send a defined number of message per day to be compliant with the rule, and our commercial contracts were designed to match this limitation.

It is a direct application of the European ETSI regulation:

  • There are 3,600 seconds in one hour.
  • 1% of 3,600 is 36 seconds, so a device can emit for 36 seconds per hour.
  • A Sigfox message takes 6 seconds to send (for RC1 devices).
  • Therefore, you can send 36/6 = 6 messages / hour, which makes 24x6 = 144 messages a day. We keep 4 messages for protocol use, which allows for 140 messages per day for your device.

NB: This calculation is just an example of what is done in EMEA region (Europe, Middle east, Africa). Depending on the location, limitations can be very different.

Emphasis added. Source: Sigfox
