Background Information

The Bambu Lab A1 mini is a compact desktop 3D printer designed as a user-friendly, feature‑rich gateway to 3D printing. With a build volume of 180 × 180 × 180 mm and a steel and extruded aluminum chassis, it combines Dual-Core Cortex M4 motion control with full-metal linear rails for high-speed precision—ability to reach 500 mm/s and 10,000 mm/s² acceleration.

It supports the AMS lite multi‑filament system for easy color prints, and extensive automation features including auto bed-leveling, Z-offset calibration, resonance tuning, filament loading/unloading, belt tension monitoring, and even pressure‑based flow calibration per print.

Technical information

Body

  • Build Volume: 180 x 180 x 180 mm3
  • Chassis: Steel and Extruded Aluminum

Toolhead

  • Hot End: All-Metal
  • Extruder Gear Material: Hardend Steel
  • Nozzle Material: Stainless Steel
  • Max Hot End Temprature: 300 °C (572 °F)
  • Included Nozzle Diameter: 0.4 mm
  • Supported Nozzle Diameters:
    • 0.2 mm
    • 0.6 mm
    • 0.8 mm
  • Filament Cutter: Yes
  • Supported Filament Diameter: 1.75 mm

Heatbed

  • Compatable Build Plates:
    • Bambu Textured PEI Plate
    • Bambu Smooth PEI Plate
    • Bambu Dual-Texture PEI Plate
  • Max Build Plate Temprature: 80°C (176 °F)

Speed

  • Max Toolhead Speed: 500 mm/s
  • Max Toolhead Acceleration: 10,000 mm2/s
  • Max Flow Rate: 28 mm3/s at ABS (Model: 150 * 150 mm single wall w/ Bambu ABS @ 280°C)

Cooling

  • Part Cooling Fan: Closed Loop Control
  • Hot End Fan: Closed Loop Control
  • MC Board Cooling Fan: Closed Loop Control

Supported Filament

  • Reccomended Filement:
    • PLA
    • PETG
    • TPU
    • PVA
  • Not Reccomended Filament:
    • ABS
    • ASA
    • PC
    • PA
    • PET
    • Carbon/Glass Fiber Reinforced Polymer

Sensors

  • Monitoring Camera: Low Rate Camera (up to1080P) Timelapse Supported
  • Filament Run Out Sensor: Yes
  • Filament Odometry: Yes
  • Power Loss Recover: Yes
  • Filament Tangle Sensor: Yes

Physical Dimensions

  • Dimensions: 347 x 315 x 365 mm3
  • Net Weight: 5.5 kg

Electrical Requirements

  • Input Voltage: 100-240 VAC, 50/60 Hz
  • Max Power: 150 W

Electronics

  • Display: 2.4 inches 320 x 240 IPS Touch Screen
  • Connectivity: Wi-Fi, Bambu-Bus
  • Storage: Micro SD Card
  • Control Interface: Touch Screen, APP, PC Application
  • Motion Controller: Dual-Core Cortex M4

Software

  • Third Party Slicer Support: Yes provided the software exports export standard Gcode such as SuperSlicer, PrusaSlicer and Cura. Certain advanced features may not be supported.
  • Slicer Supported OS:

Wi-Fi

  • Frequency Range:
    • 2412 MHz - 2472 MHz (CE)
    • 2412 MHz - 2462 MHz (FCC)
    • 2400 MHz - 2483.5 MHz (SRRC)
  • Transmitter Power (EIRP):
    • ≤ 21.5 dBm (FCC)
    • ≤ 20 dBm (CE/SRRC)
  • Protocol: IEEE 802.11 b/g/n
