LTspice error, EKG

Question

I got these errors. What should I do?

Circuit: * C:\Users\hp\Documents\LTspiceXVII\EKG Schaltung.asc
Error on line 10 : c3 n002 n009 470 pf
     Unknown parameter "pf"
Error on line 13 : c1 n005 n004 3.3 mu
     Unknown parameter "mu"
WARNING: Less than two connections to node NC_01.  This node is used by V1.
WARNING: Less than two connections to node NC_02.  This node is used by V2.
Direct Newton iteration for .op point succeeded.
