Acer Aspire 5253 RAM Replacement

Written By: Cynthia Barajas

Comments: 2

Difficulty

Easy

Steps

Time Required

5 minutes

Introduction

Make sure to remove the battery first to avoid any incidents.

Tools

Step 1

Turn the laptop over.

Step 2

"Unlock" your battery by moving the switch as shown so that an unlocked lock on a red background is shown.

Step 3

Next move the other switch, while the unlocked symbol is still showing. The battery should pop up, and no longer be flush with the bottom of the laptop.

Step 4

Now remove the battery by lifting it out of the laptop by the side closest to the switches.

Step 5

You have successfully removed the battery. Congratulations!

Step 6

Now, locate the two screws that hold the back cover panel onto the laptop.

Step 7

Unscrew both of the screws that are holding the back panel in place with the Philips #00 head.
The screws are 3/8" in length and have a 1/4" head.

Step 8

Once both screws have been removed use a plastic opening tool to lift the panel up. Starting with the indented notch , and moving left and right from there.

Step 9

After the panel has been loosened by the plastic opening tool, take your finger, place it in the gap, and remove the panel from the laptop.
