Background and Identification
Released in 2013, the Lenovo B590 is a 15.6” business laptop designed for use in offices and small businesses. At 5.5 lbs, the B590 features a 15.6 -inch HD AntiGlare display with a screen resolution of 1366 x 768 and an aspect ratio of 16:9. The display is further supported by an Intel HD graphics processor.
The B590 is available in a range of versions depending on the type of processor, RAM, and storage capacity. Features found across all versions include an AccuType ergonomic keyboard, a multi-touch touchpad with two buttons, 10/100/1000Mbps gigabit Ethernet, a Lenovo BGN wireless card, 802.11 b/g/n Wi-Fi, Bluetooth 4.0, and a battery life of up to six hours.
Technical Specifications
For the Core i3 2328M, 4GB RAM, 500 GB HDD version
- Processor/Chipset:
- CPU: Intel Core i3 (2nd Gen) 2328M / 2.2 GHz
- Number of Cores: Dual-Core
- Cache: 3 MB
- 64-bit Computing: Yes
- Chipset Type: Mobile Intel HM77 Express
- Features: Hyper-Threading Technology, integrated memory controller
- Cache Memory:
- Installed Size: 3 MB
- RAM:
- Memory Speed: 1333 MHz
- Memory Specification Compliance: PC3-12800
- Technology: DDR3 SDRAM
- Installed Size: 4 GB
- Rated Memory Speed: 1600 MHz
- Storage:
- Interface: Serial ATA-300
- Memory:
- Max Supported Size: 8 GB
- Technology: DDR3 SDRAM
- Speed: 1333 MHz / PC3-12800
- Form Factor: SO-DIMM 204-pin
- Slots Qty: 2
- Display:
- LCD Backlight Technology: LED backlight
- Widescreen Display: Yes
- Image Aspect Ratio: 16:9
- Monitor Features: Anti-glare
- Type: LED
- Diagonal Size (metric): 39.6 cm
- Display Resolution Abbreviation: HD
- Audio & Video:
- Graphics Processor: Intel HD Graphics 3000
- Integrated Webcam: Yes
- Capture Resolutions: 1280 x 720
- Sound: Stereo speakers, microphone
- Audio Codec: Realtek ALC269Q
- Hard Drive:
- Spindle Speed: 5400 rpm
- Type: HDD
- Capacity: 500 GB
- Input:
- Type: Keyboard, touchpad
- Features: Multi-touch touchpad
- Communications:
- Wireless Protocol: 802.11b/g/n, Bluetooth 4.0
- Wireless Controller: ThinkPad 11 b/g/n - PCI Express Mini Card
- Wired Protocol: Gigabit Ethernet
- Wireless Broadband (WWAN)
- Generation: 3G: upgradeabke
- Card Reader:
- Type: 4 in 1 card reader
- Supported Flash Memory: MultiMediaCard, SD Memory Card, SDHC Memory Card, SDXC Memory Card
- Battery:
- Cells: 6-cell
- Technology: lithium ion
- Run Time (Up To): 6 hour(s)
- AC Adapter:
- Input: AC 120/230 V (50/60 Hz)
- Output: 65 Watt
- OS: Microsoft Windows 7 Professional 64-bit Edition
- Dimensions & Weight:
- Width: 14.9 in
- Depth: 9.9 in
- Height: 1.3 in
